DS4 Back Panel AC INPUT: Connect the female end of the AC line cord here.
Dean markly external pickup canada full#
The Limiter allows the amplifier to be played at full power without unwanted distortion. If the power amplifier reaches full power output, the on board Limiter will be enabled and this LED will turn RED. PILOT LIGHT/LIMIT INDICATOR: When GREEN, this LED indicates that the power is turned on. MASTER VOLUME: Adjusts the overall loudness of the amplifier. MODE: (DIGITAL EFX) This is a rotary encoder, which selects 1 of 16 different digital effects.
LEVEL: (DIGITAL EFX) Controls the amount of digital effect mixed in to the guitar signal from 0% to 50% (CH-1)(CH-2): (DIGITAL EFX Assign): This 3 way toggle switch allows the digital effects to be routed to CH-1, CH-2, or if in the middle position will supply effects for both channels.In the on position the mid frequencies will be cut and the high and low frequencies will be boosted. Shape: ON/OFF This toggle switch enables or disables the SHAPE control. Notch Filter: ON/OFF - Enables or disables the notch filter control. Notch Filter HZ: Sets the frequency of the 18db cut NOTCH FILTER that is used to control resonant feedback. VOLUME: Controls the overall volume of CHANNEL-2. With the myriad of guitars, pick-up systems, and playing styles out there, one of the channels will sound great with your gear. (Channel-2 is designed primarily for acoustic guitar) Try both channels to find out which channel works best for your application, some players like Channel-1 and others prefer Channel-2. INPUT-2: Combo Input designed for both MIC level (XLR) and Instrument level (¼") signals.TREBLE: Adjusts the amount of cut or boost in the high frequency range.
VOLUME: Controls the overall volume level of CHANNEL-1.īASS: Adjusts the amount of cut or boost in the low frequency range. It accepts both balanced and unbalanced inputs) (Channel-1 is designed as a generic "flat response" channel which is suitable for any acoustic instrument level or microphone signal) (The ¼" TRS Tip/Ring/Sleeve input jack is suited for equipment such as high-impedance microphones, keyboards and drum machines.
